3VL41403KN300AA0

circuit breaker VL400 UL; type JG (cat no. LJX3B400) non-interchangeable frame, with circuit breaker approval acc. to UL 489 very

Manufacturer's No: 3VL4140-3KN30-0AA0     Manufacturer: Siemens
circuit breaker VL400 UL; type JG (cat no. LJX3B400) non-interchangeable frame, with circuit breaker approval acc. to UL 489 very high breaking cap...

Availability On Request

POA
  • Circuit breaker VL400 UL
  • Type JG (cat no. LJX3B400)
  • Non-interchangeable frame
  • UL 489 approval
  • Very high breaking capacity: 100kA/480V
  • 3-pole NEMA rating
  • Molded case circuit breaker
  • Electronic Trip Unit TM
  • Rated current: In < 400A
  • Short-circuit protection: IR = 400A

Read more

  • Line protection only
  • No connection accessories, auxiliary release, or alarm switch included
  • Spare part for replacement usage only


Product

Manufacturer Material ID -
3VL4140-3KN30-0AA0
Net Weight -
5.70kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
DE
Export Control Regulations -
EAR99 / N
UNSPSC -
39121601

Technical Specification

Complete device with protection unit -
Degree of protection (IP rating) -
IP20
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Motor drive optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Power loss -
175 Watt
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
100 kiloampere
Suitable for DIN rail (top hat rail) mounting -

Availability On Request

POA
