3KD04302LG203

Switch disconnector 80A, size 02, 3-pole Front operating mechanism center Basic unit without handle Box terminal

Manufacturer's No: 3KD0430-2LG20-3     Manufacturer: Siemens
Switch disconnector 80A, size 02, 3-pole Front operating mechanism center Basic unit without handle Box terminal

Availability On Request

£57.17
  • Switch disconnector
  • 80A current rating
  • Size 02
  • 3-pole configuration
  • Front operating mechanism at center
  • Basic unit without handle
  • Box terminal

Selectable mandatory product

Accessories

Product video
Product video


Product

Manufacturer Material ID -
3KD0430-2LG20-3
Net Weight -
0.44kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
UNSPSC -
39122221

Technical Specification

Degree of protection (IP), front side -
IP10
Max. rated operation voltage Ue AC -
690 Volt
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
2
Number of auxiliary contacts as normally open contact -
2
Number of poles -
3
Number of switches -
1
Rated operation power at AC-23, 400 V -
37 Kilowatt
Rated permanent current at AC-21, 400 V -
80 Ampere
Rated permanent current at AC-23, 400 V -
75 Ampere
Rated permanent current Iu -
80 Ampere
Rated short-time withstand current lcw -
2.5 kiloampere
Suitable for floor mounting -
Type of electrical connection of main circuit -
Frame clamp
Version as emergency stop installation -
Version as main switch -
Version as maintenance-/service switch -
Version as safety switch -

Availability On Request

£57.17
