3RG90040DC00

AS-i module F90, IP20, digital, 4 I/4 Q, 2/3-wire, floating 4x1 input

Manufacturer's No: 3RG9004-0DC00     Manufacturer: Siemens
AS-i module F90, IP20, digital, 4 I/4 Q, 2/3-wire, floating 4x1 input

Availability On Request

£186.43
  • AS-i module F90
  • IP20 rated
  • Digital module
  • 4 inputs / 4 outputs
  • Supports 2/3-wire sensors
  • Floating 4x1 input
  • External sensor supply
  • 4 outputs, 2A each, 24V DC
  • Max total output current: 6A
  • Connection via Combicon

Read more

  • Width: 90mm
  • Requires Combicon connector set 3RX9810-0AA00

Mandatory additional product



Product

Manufacturer Material ID -
3RG9004-0DC00
Net Weight -
0.08kg

Additional Product Information

Commodity Code -
85371098
Country of Origin -
CZ
RoHs Compliance -
Yes
UNSPSC -
39121521

Technical Specification

Time delay at signal exchange -
- Millisecond
Category according to EN 954-1 -
UN
Performance level acc. EN ISO 13849-1 -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Supply voltage DC -
- Volt
Permitted voltage at output -
- Volt
Permitted voltage at input -
- Volt
SIL according to IEC 61508 -
UN
Degree of protection (IP) -
IP20
Number of interfaces PROFINET -
0
Type of digital output -
Other
Explosion safety category for gas -
None
Explosion safety category for dust -
None
Degree of protection (IP rating) -
IP20
Depth -
37 Millimetre
Height -
75 Millimetre
Input current at signal 1 -
5 Milliampere
Number of digital inputs -
4
Number of digital outputs -
4
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces Wireless -
0
Output current -
2 Ampere
Short-circuit protection, outputs available -
Supporting protocol for ASI -
System accessory -
Type of electric connection -
Other
Type of output voltage -
DC
Type of voltage (input voltage) -
DC
Voltage type of supply voltage -
DC
Width -
90 Millimetre

Availability On Request

£186.43
