3VA26127HM320AA0

circuit breaker 3VA2 IEC Frame 1250 breaking capacity class C Icu=110 kA @ 415 V 3-pole, line protection ETU330, LIG, In=1250 A o

Manufacturer's No: 3VA2612-7HM32-0AA0     Manufacturer: Siemens
circuit breaker 3VA2 IEC Frame 1250 breaking capacity class C Icu=110 kA @ 415 V 3-pole, line protection ETU330,  LIG, In=1250 A overload protectio...

Availability On Request

£4,496.61
  • Circuit Breaker: 3VA2 IEC Frame 1250
  • Breaking Capacity: Class C, Icu=110 kA @ 415 V
  • Configuration: 3-pole, line protection
  • Overload Protection: In=1250 A, Ir=500 A ... 1250 A
  • Short-Circuit Protection: Ii=1.5...10 x In
  • Ground-Fault Protection: Ig=0.2...1 x In, tg=0.1/0.3s
  • Bus Connectors: Broadened

Accessories

Presentation video
Question and Answer (Q&A video)
Product video
Presentation video
Question and Answer (Q&A video)
Product video


Product

Manufacturer Material ID -
3VA2612-7HM32-0AA0
Net Weight -
20.76kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121601

Technical Specification

Degree of protection (IP) -
IP40
Type of electrical connection of main circuit -
Other
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz -
110 kiloampere
Adjustment range undelayed short-circuit release -
1875 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Integrated earth fault protection -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Overload release current setting -
500 Ampere
Position of connection for main current circuit -
Front
Power loss -
516 Watt
Rated permanent current Iu -
1250 Ampere
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
110 kiloampere
Rated voltage -
690 Volt
Type of control element -
Rocker lever

Availability On Request

£4,496.61
