3VA51126EC311AA0

Circuit breaker 3VA5 UL frame 125 breaking capacity class H 65 kA @ 480 V 3-pole

Manufacturer's No: 3VA5112-6EC31-1AA0     Manufacturer: Siemens
Circuit breaker 3VA5 UL frame 125 breaking capacity class H 65 kA @ 480 V 3-pole

Availability On Request

£572.11
  • Circuit Breaker: 3VA5 UL Frame 125
  • Breaking Capacity: 65 kA @ 480V
  • Number of Poles: 3
  • Line Protection: TM230, FTAM
  • Overload Protection: In=125A
  • Short-Circuit Protection: Ir=125A
  • Short-Circuit Protection Setting: Ii=5-10 x In
  • UL 489 SB (Naval) certified
  • Operating Temperature: 50°C
  • Suitable for use without connection

Accessories

Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA5112-6EC31-1AA0
Net Weight -
0.88kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
RoHs Compliance -
Yes
UNSPSC -
39121601

Technical Specification

Rated short-circuit breaking capacity lcu at 400 V, 50 Hz -
- kiloampere
Adjustment range short-term delayed short-circuit release -
- Ampere
Degree of protection (IP) -
IP40
Position of connection for main current circuit -
Other
Type of electrical connection of main circuit -
Other
Adjustment range undelayed short-circuit release -
625 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
Motor drive optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Overload release current setting -
125 Ampere
Power loss -
30.1 Watt
Rated permanent current Iu -
125 Ampere
Rated voltage -
690 Volt
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever

Availability On Request

£572.11
