3VA52101BB410AA0

MCS_UL_FS250_100A_4P_100kA

Manufacturer's No: 3VA5210-1BB41-0AA0     Manufacturer: Siemens
MCS_UL_FS250_100A_4P_100kA

Availability On Request

£672.80
  • Molded case switch 3VA5 UL frame 250
  • Max short-circuit current rating: 100kA @ 480V
  • 4-pole MCS110
  • Rated current: 100A
  • Self-protection feature: Ii=25 x In without connection
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA5210-1BB41-0AA0
Net Weight -
2.70kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121601

Technical Specification

Position of connection for main current circuit -
Other
Type of electrical connection of main circuit -
Other
Adjustment range undelayed short-circuit release -
2500 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
Motor drive optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
4
Power loss -
8.7 Watt
Rated permanent current Iu -
100 Ampere
Rated voltage -
690 Volt
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever

Availability On Request

£672.80
