3VA52305ED361AA0

circuit breaker 3VA5 UL Frame 250 breaking capacity class M 35 kA @ 480 V 3-pole, line protection TM210, FTFM, In=30 A overload p

Manufacturer's No: 3VA5230-5ED36-1AA0     Manufacturer: Siemens
circuit breaker 3VA5 UL Frame 250 breaking capacity class M 35 kA @ 480 V 3-pole, line protection TM210,  FTFM, In=30 A overload protection Ir=30 A...

Availability On Request

£507.50
  • Circuit breaker 3VA5 UL Frame 250
  • Breaking capacity: 35 kA @ 480 V
  • 3-pole, line protection TM210
  • Overload protection: In=30 A
  • Short-circuit protection: Ir=30 A
  • Short-circuit protection setting: Ii=11.67 x In
  • UL489 SB (naval) certified
  • Cable connection on two sides
  • Operating temperature: 50 degrees Celsius
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA5230-5ED36-1AA0
Net Weight -
2.10kg

Additional Product Information

Commodity Code -
8536200020
Country of Origin -
CZ
UNSPSC -
39121601

Technical Specification

Adjustment range undelayed short-circuit release -
400 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Motor drive optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Overload release current setting -
30 Ampere
Position of connection for main current circuit -
Front
Power loss -
18.5 Watt
Rated permanent current Iu -
30 Ampere
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
55 kiloampere
Rated voltage -
690 Volt
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever

Availability On Request

£507.50
