3VA54456EC311AA0

Circuit breaker 3VA5 UL frame 600 breaking capacity class H 65 kA @ 480 V 3-pole

Manufacturer's No: 3VA5445-6EC31-1AA0     Manufacturer: Siemens
Circuit breaker 3VA5 UL frame 600 breaking capacity class H 65 kA @ 480 V 3-pole

Availability On Request

£1,760.94
  • Circuit breaker: 3VA5 UL Frame 600
  • Breaking capacity: 65 kA @ 480 V
  • 3-pole, line protection
  • Overload protection: In=450 A
  • Short-circuit protection: Ir=450 A
  • Short-circuit protection setting: Ii=5...10 x In
  • UL489 SB (naval) certified
  • Operating temperature: 50 degrees Celsius
  • Suitable for applications without connection

Accessories

Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA5445-6EC31-1AA0
Net Weight -
5.20kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121601

Technical Specification

Adjustment range undelayed short-circuit release -
2250 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Motor drive optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Overload release current setting -
450 Ampere
Power loss -
99 Watt
Rated permanent current Iu -
450 Ampere
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever
