3VA55600MH360AA0

Circuit breaker 3VA5 UL frame 800 max. short-circuit breaking capacity without contactor

Manufacturer's No: 3VA5560-0MH36-0AA0     Manufacturer: Siemens
Circuit breaker 3VA5 UL frame 800 max. short-circuit breaking capacity without contactor

Availability On Request

£2,663.02
  • Circuit breaker 3VA5 UL frame 800
  • Maximum short-circuit current rating: 65 kA @ 480 V
  • 3-pole with motor starter protection TM120M, AM, In=600A
  • Short circuit protection Ii=3...15 x In
  • Aluminum lugs on line and load side
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA5560-0MH36-0AA0
Net Weight -
14.59kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121601

Technical Specification

Adjustment range undelayed short-circuit release -
4800 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Position of connection for main current circuit -
Front
Power loss -
120 Watt
Rated permanent current Iu -
600 Ampere
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
70 kiloampere
Rated voltage -
690 Volt
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever

Availability On Request

£2,663.02
