3VA55705GC462AA0

Circuit breaker 3VA5 UL frame 800 breaking capacity class M 35 kA @ 480 V 4-pole

Manufacturer's No: 3VA5570-5GC46-2AA0     Manufacturer: Siemens
Circuit breaker 3VA5 UL frame 800 breaking capacity class M 35 kA @ 480 V 4-pole

Availability On Request

£3,335.00
  • Circuit Breaker: 3VA5 UL Frame 800
  • Breaking Capacity: 35 kA @ 480 V
  • Configuration: 4-pole
  • Line Protection: TM230, FTAM
  • Overload Protection: In=700 A
  • Short-Circuit Protection: Ir=700 A
  • Neutral Conductor Protection
  • Cable Connection on Two Sides
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA5570-5GC46-2AA0
Net Weight -
18.72kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
MX
UNSPSC -
26101109

Technical Specification

Type of electrical connection of main circuit -
Other
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz -
55 kiloampere
Adjustment range undelayed short-circuit release -
3500 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
4
Overload release current setting -
700 Ampere
Position of connection for main current circuit -
Front
Power loss -
183 Watt
Rated permanent current Iu -
700 Ampere
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
55 kiloampere
Rated voltage -
690 Volt
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever

Availability On Request

£3,335.00
