3VA55807EC460AA0

Circuit breaker 3VA5 UL frame 800 breaking capacity class C 100 kA @ 480 V 4-pole

Manufacturer's No: 3VA5580-7EC46-0AA0     Manufacturer: Siemens
Circuit breaker 3VA5 UL frame 800 breaking capacity class C 100 kA @ 480 V 4-pole

Availability On Request

£4,200.47
  • Circuit Breaker 3VA5 UL Frame 800
  • Breaking Capacity: 100 kA @ 480 V
  • 4-Pole, Line Protection TM230, FTAM
  • Rated Current: 800 A
  • Overload Protection: Ir = 800 A
  • Short-Circuit Protection: Ii = 5-10 x In
  • N Conductor Unprotected Cable Connection on Two Sides
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA5580-7EC46-0AA0
Net Weight -
21.92kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121601

Technical Specification

Adjustment range undelayed short-circuit release -
4000 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
4
Overload release current setting -
800 Ampere
Position of connection for main current circuit -
Front
Power loss -
210 Watt
Rated permanent current Iu -
800 Ampere
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
110 kiloampere
Rated voltage -
690 Volt
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever

Availability On Request

£4,200.47
