2CPX041314R9999

MT143 NH1-fuse switch disconnector 750 mm x 250 mm x 200 mm , 1

Manufacturer's No: 41314     Manufacturer: ABB
MT143 NH1-fuse switch disconnector 750 mm x 250 mm x 200 mm , 1

Availability Back Order

£222.29
  • MT143 NH1-fuse switch disconnector
  • Dimensions: 750 mm x 250 mm x 200 mm
  • Interior fitting module, CombiLine
  • Grid unit 5 GU = 750 mm, panel width 1 = 250 mm
  • 60 Space units, unequipped for the installation of 2 NH-fuse disconnectors NH1
  • Busbar system 3-pole, rated current maximum 630 A
  • Plastic covers with 90-degree press and turn closure, RAL 7035
  • Cover design: with cut-out, usable from cabinet depth of 200 mm


Product

Manufacturer Material ID -
41314
Net Weight -
2.54kg

Additional Product Information

Commodity Code -
85381000
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
31261502

Technical Specification

Construction size -
NH1
Depth -
200 Millimetre
Height -
750 Millimetre
Mounting method -
Mounting plate
Number of fuse switch disconnectors -
2
Number of knife blade fuse holders -
0
Number of poles -
3
Rated current -
630 Ampere
Width -
250 Millimetre
With cover -
ABB

Availability Back Order

£222.29
