4AV98071CB002N

CURRENT SUPPLY (UNSCREENED); PHASES:1; PN(KW):0,08; UPRI(V):400; USEC(V DC):24; ISEC(A DC):3,33; F(H

Manufacturer's No: 4AV9807-1CB00-2N     Manufacturer: Siemens
CURRENT SUPPLY (UNSCREENED); PHASES:1; PN(KW):0,08; UPRI(V):400; USEC(V DC):24; ISEC(A DC):3,33; F(H

Availability On Request

£222.00
  • Phases: 1
  • Power (kW): 0.08
  • Primary Voltage (V): 400
  • Secondary Voltage DC (V): 24
  • Secondary Current DC (A): 3.33
  • Frequency (Hz): 50...60
  • Vector Group/Shield Winding: II0 / 0
  • Protection Class: I
  • Temperature Class/Insulation Class: 50 / B
  • Efficiency (%): 48.3

Read more

  • Enclosure: IP00
  • Type of Terminals: Screw/Tab Connection
  • Installation: Screw
  • Complies with EN 61558 Safety Isolating Transformer


Product

Manufacturer Material ID -
4AV9807-1CB00-2N
Net Weight -
2.40kg

Additional Product Information

Commodity Code -
85043180
Country of Origin -
CZ
Export Control Regulations -
N / N
UNSPSC -
39121002

Technical Specification

Built-in height -
- Millimetre
Power consumption -
- Voltampere
Width in number of modular spacings -
-
Power output -
- Watt
2nd secondary output voltage -
- Volt
3rd secondary output voltage -
- Volt
Rated supply voltage at AC 50 Hz -
- Volt
Rated supply voltage at AC 60 Hz -
- Volt
Rated supply voltage at DC -
- Volt
Performance level acc. EN ISO 13849-1 -
UN
Max. output current 2 -
- Ampere
Max. output current 3 -
- Ampere
Nominal value output voltage 1 -
- Volt
Nominal value output voltage 2 -
- Volt
Nominal value output voltage 3 -
- Volt
Nominal value output current 1 -
- Ampere
Nominal value output current 2 -
- Ampere
Nominal value output current 3 -
- Ampere
SIL according to IEC 61508 -
UN
Degree of protection (NEMA) -
UN
Built-in width -
127 Millimetre
Degree of protection (IP) -
IP00
Type of electric connection -
Other
Rail mounting possible -
1st secondary output voltage -
24 Volt
Degree of protection (IP rating) -
IP00
Depth -
93 Millimetre
Height -
95 Millimetre
Max. output current 1 -
3.33 Ampere
Recess width -
127 Millimetre
Voltage type of supply voltage -
AC
Width -
127 Millimetre

Availability On Request

£222.00
Sign in or Register for customer prices.

Additional Information

Did you know, we are an entrusted Siemens approved partner?
