5SD74112

Lightning arrester Type 1, 1-pole, for 2-wire networks (L, pen), UC 800V AC with remote signaling No

Manufacturer's No: 5SD7411-2     Manufacturer: Siemens
Lightning arrester Type 1, 1-pole, for 2-wire networks (L, pen), UC 800V AC with remote signaling No

Availability Available to order

£594.94
  • Type 1 lightning arrester
  • 1-pole design for 2-wire networks (L, pen)
  • Maximum operating voltage: 800V AC
  • Remote signaling feature
  • Not a modular installation device
Product video
Product video


Product

Manufacturer Material ID -
5SD7411-2
Net Weight -
3.52kg

Additional Product Information

Commodity Code -
85363090
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Nominal voltage DC -
- Volt
Voltage protection level L-N -
- Kilovolt
Max. continuous voltage DC -
- Volt
Max. PV-voltage -
- Volt
Voltage protection level N-PE -
- Kilovolt
Max. continuous voltage AC -
800 Volt
Nominal discharge surge current (8/20) -
100 kiloampere
Category type 2 -
Degree of protection (IP) -
IP20
Construction size -
Other
Signalling at the device -
None
Degree of protection (IP rating) -
IP20
Max. conductor cross section flexible (fine-strand) -
50 Square millimetre
Max. conductor cross section solid (solid, stranded) -
50 Square millimetre
Max. discharge surge current (8/20) -
100 kiloampere
Max. overcurrent protection device, parallel connection (fuse) -
400 Ampere
Max. overcurrent protection device, series connection (fuse) -
125 Ampere
Max. voltage (Uc) -
800 Volt
Mounting method -
Other
Nominal discharge surge current 8/20 µs (In) -
100 kiloampere
Nominal voltage AC -
690 Volt
Number of conductors (without earthing) -
1
Short-circuit breaking capacity (Isccr) -
50 kiloampere
Type / Test class 2 -
Voltage protection level -
4.5 Kilovolt
With remote signalling contact -
Commodity Code -
85363090

Availability Available to order

£594.94
