5SD74611

Surge arrester Type 2 Requirement class C, UC 350V Pluggable protective modules 1-pole, L-N circuit

Manufacturer's No: 5SD7461-1     Manufacturer: Siemens
Surge arrester Type 2 Requirement class C, UC 350V Pluggable protective modules 1-pole, L-N circuit

Availability Back Order

£102.34
  • Surge arrester Type 2 Requirement class C
  • UC 350V
  • Pluggable protective modules
  • 1-pole, L-N circuit
  • Remote display

Component part

Product video
Product video


Product

Manufacturer Material ID -
5SD7461-1
Net Weight -
0.15kg

Additional Product Information

Commodity Code -
85363090
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39122330

Technical Specification

Nominal voltage DC -
- Volt
Voltage protection level L-N -
- Kilovolt
Max. continuous voltage DC -
- Volt
Max. PV-voltage -
- Volt
Voltage protection level N-PE -
- Kilovolt
Max. continuous voltage AC -
350 Volt
Nominal discharge surge current (8/20) -
40 kiloampere
Category type 2 -
Degree of protection (IP) -
IP20
Mounting method -
DIN rail (top hat rail) 35 mm
Signalling at the device -
Optic
Construction size -
1 modular spacing
Degree of protection (IP rating) -
IP20
Max. conductor cross section flexible (fine-strand) -
25 Square millimetre
Max. conductor cross section solid (solid, stranded) -
35 Square millimetre
Max. discharge surge current (8/20) -
40 kiloampere
Max. overcurrent protection device, parallel connection (fuse) -
125 Ampere
Max. voltage (Uc) -
350 Volt
Nominal discharge surge current 8/20 µs (In) -
40 kiloampere
Nominal voltage AC -
230 Volt
Number of conductors (without earthing) -
1
Short-circuit breaking capacity (Isccr) -
25 kiloampere
Type / Test class 2 -
Voltage protection level -
1.4 Kilovolt
With remote signalling contact -

Availability Back Order

£102.34
