5SM36456

Residual current operated circuit breaker, 4-pole, type A, In: 125 A, 300 mA, Un AC: 400 V

Manufacturer's No: 5SM3645-6     Manufacturer: Siemens
Residual current operated circuit breaker, 4-pole, type A, In: 125 A, 300 mA, Un AC: 400 V

Availability On Request

POA

This product has been superseded by

5SV36456

Please check compatibility before purchasing.

  • Residual current operated circuit breaker
  • 4-pole, type A
  • Rated current (In): 125 A
  • Sensitivity: 300 mA
  • Rated voltage (Un AC): 400 V
  • Discontinued since: 15/06/23
  • Successor model: 5SV3645-6

Accessories

Price £0.0836
On Request
Price £0.0836
On Request

Follow-up article



Product

Manufacturer Material ID -
5SM3645-6
Net Weight -
0.52kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Rated insulation voltage Ui -
- Volt
Pollution degree -
-
Rated impulse withstand voltage Uimp -
- Kilovolt
Built-in depth -
70 Millimetre
Degree of protection (IP) -
IP20
Mounting method -
DIN rail
Degree of protection (IP rating) -
IP20
Additional equipment possible -
Ambient temperature during operating -
-25 Degrees celsius
Connectable conductor cross section multi-wired -
2.5 Square millimetre
Connectable conductor cross section solid-core -
2.5 Square millimetre
Frequency -
50 Hz
Leakage current type -
A
Number of poles -
4
Power loss -
8.9 Watt
RAL-number (similar) -
7035
Rated current -
125 Ampere
Rated fault current -
0.3 Ampere
Rated voltage -
400 Volt
Recess depth -
70 Millimetre
Short-circuit breaking capacity (Icw) -
10 kiloampere
Surge current capacity -
1 kiloampere
Voltage type -
AC
Width in number of modular spacings -
4
With interlocking device -

Availability On Request

POA
Sign in or Register for customer prices.

This product has been superseded by

5SV36456

Please check compatibility before purchasing.
