5SU13544KK16

RCBO, 10 kA, 1P+N, type F, short-time-delayed K, 30 mA, C-Char, In: 16 A, Un AC: 230 V

Manufacturer's No: 5SU1354-4KK16     Manufacturer: Siemens

Availability Back Order

£155.72
  • RCBO (Residual Current Circuit Breaker with Overcurrent Protection)
  • 10 kA breaking capacity
  • 1P+N poles
  • Type F
  • Super-resistant K
  • 30 mA sensitivity
  • C-Char trip curve
  • Rated current: 16 A
  • Rated voltage: 230 V AC

Selectable mandatory product

Accessories



Product

Manufacturer Material ID -
5SU1354-4KK16
Net Weight -
0.27kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
RO
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Built-in depth -
70 Millimetre
Release characteristic -
C
Degree of protection (IP) -
IP20
Suitable for flush-mounted installation -
Rated impulse withstand voltage Uimp -
4 Kilovolt
Rated short-circuit breaking capacity Icn acc. EN 61009-1 -
10 kiloampere
Rated short-circuit breaking capacity acc. EN 61009 -
10 kiloampere
Over voltage category -
2
Frequency -
50 Hz
Degree of protection (IP rating) -
IP20
Ambient temperature during operating -
-25 Degrees celsius
Disconnection characteristic -
Other
Anti-nuisance tripping version -
Concurrently switching N-neutral -
Connectable conductor cross section multi-wired -
0.75 Square millimetre
Connectable conductor cross section solid-core -
0.75 Square millimetre
Current limiting class -
3
Flush-mounted installation -
Leakage current type -
F
Number of poles (total) -
2
Number of protected poles -
1
Pollution degree -
2
Rated current -
16 Ampere
Rated fault current -
0.03 Ampere
Rated impulse-withstand voltage (Uimp) -
4 Kilovolt
Rated insulation voltage Ui -
264 Volt
Rated short-circuit breaking capacity according to EN 61009 -
10 kiloampere
Rated short-circuit breaking capacity Icn according to EN 61009-1 -
10 kiloampere
Rated short-circuit breaking capacity IEC 60947-2 -
20 kiloampere
Rated voltage -
230 Volt
Recess depth -
70 Millimetre
Surge current capacity -
3 kiloampere
Tripping characteristic (type/curve) -
C
Voltage type -
AC
Width in number of modular spacings -
2
With interlocking device -
