5SU13748DK81

RCBO, 10 kA, 4P, type B+, short-time delayed K, 30 mA, D-char, In: 100 A

Manufacturer's No: 5SU1374-8DK81     Manufacturer: Siemens
RCBO, 10 kA, 4P, type B+, short-time delayed K, 30 mA, D-char, In: 100 A

Availability On Request

£4,253.32
  • RCBO (Residual Current Circuit Breaker with Overcurrent Protection)
  • 10 kA breaking capacity
  • 4 poles
  • Type B+ curve
  • Short-time delayed
  • 30 mA sensitivity
  • D characteristic
  • Rated current: 100 A
  • Rated voltage: 400 V AC

Accessories



Product

Manufacturer Material ID -
5SU1374-8DK81
Net Weight -
2.08kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121601

Technical Specification

Anti-nuisance tripping version -
Concurrently switching N-neutral -
Connectable conductor cross section multi-wired -
6 Square millimetre
Connectable conductor cross section solid-core -
6 Square millimetre
Current limiting class -
3
Flush-mounted installation -
Leakage current type -
B+
Number of poles (total) -
4
Number of protected poles -
4
Pollution degree -
2
Rated current -
100 Ampere
Rated fault current -
0.03 Ampere
Rated impulse-withstand voltage (Uimp) -
4 Kilovolt
Rated insulation voltage Ui -
440 Volt
Rated short-circuit breaking capacity according to EN 61009 -
10 kiloampere
Rated short-circuit breaking capacity Icn according to EN 61009-1 -
10 kiloampere
Rated short-circuit breaking capacity IEC 60947-2 -
10 kiloampere
Rated voltage -
400 Volt
Recess depth -
70 Millimetre
Surge current capacity -
3 kiloampere
Tripping characteristic (type/curve) -
D
Voltage type -
AC
Width in number of modular spacings -
11
With interlocking device -

Availability On Request

£4,253.32
