5SV13137KK16

RCBO compact 1P+N 4.5 kA type A 30 mA C16

Manufacturer's No: 5SV1313-7KK16     Manufacturer: Siemens
RCBO compact 1P+N 4.5 kA type A 30 mA C16

View 3D

Availability Back Order

£116.37
  • RCBO (Residual Current Breaker with Overcurrent Protection)
  • Compact design
  • 1-pole+N configuration
  • 4.5 kA short-circuit breaking capacity
  • Type A sensitivity
  • 30 mA rated residual current
  • C16 rated current

Selectable mandatory product

Accessories



Product

Manufacturer Material ID -
5SV1313-7KK16
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
RO
UNSPSC -
39121601

Technical Specification

Built-in depth -
70 Millimetre
Release characteristic -
C
Degree of protection (IP) -
IP20
Suitable for flush-mounted installation -
Rated impulse withstand voltage Uimp -
4 Kilovolt
Rated short-circuit breaking capacity Icn acc. EN 61009-1 -
4.5 kiloampere
Rated short-circuit breaking capacity acc. EN 61009 -
4.5 kiloampere
Over voltage category -
2
Frequency -
50 Hz
Degree of protection (IP rating) -
IP20
Ambient temperature during operating -
-25 Degrees celsius
Anti-nuisance tripping version -
Concurrently switching N-neutral -
Connectable conductor cross section multi-wired -
0.75 Square millimetre
Connectable conductor cross section solid-core -
0.75 Square millimetre
Current limiting class -
3
Disconnection characteristic -
Undelayed
Flush-mounted installation -
Leakage current type -
A
Number of poles (total) -
2
Number of protected poles -
1
Pollution degree -
2
Rated current -
16 Ampere
Rated fault current -
0.03 Ampere
Rated impulse-withstand voltage (Uimp) -
4 Kilovolt
Rated insulation voltage Ui -
253 Volt
Rated short-circuit breaking capacity according to EN 61009 -
4.5 kiloampere
Rated short-circuit breaking capacity Icn according to EN 61009-1 -
4.5 kiloampere
Rated short-circuit breaking capacity IEC 60947-2 -
5 kiloampere
Rated voltage -
230 Volt
Recess depth -
70 Millimetre
Surge current capacity -
1 kiloampere
Tripping characteristic (type/curve) -
C
Voltage type -
AC
Width in number of modular spacings -
1
With interlocking device -
