5TE8153

Two-way switch 20 A 3 NO 1 NC

Manufacturer's No: 5TE8153     Manufacturer: Siemens
Two-way switch 20 A 3 NO 1 NC

Availability On Request

£87.40
  • Two-way switch
  • 20A
  • 3 Normally Open (NO) contacts
  • 1 Normally Closed (NC) contact

Accessories



Product

Manufacturer Material ID -
5TE8153
Net Weight -
0.09kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
RO
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Max. lamp power -
- Watt
Min. rated voltage -
- Volt
Number of contacts as change-over contact -
-
Built-in depth -
70 Millimetre
Lamp type -
Other
Colour calotte -
Other
Degree of protection (IP) -
Other
Light source type -
Other
Colour light source -
Other
Lamp socket -
Other
Degree of protection (IP rating) -
Other
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
3
Number of poles -
1
Rated current -
20 Ampere
Rated switching capacity -
0.06 kiloampere
Rated voltage -
400 Volt
Recess depth -
70 Millimetre
Short-circuit breaking capacity (Icw) -
10 kiloampere
Switching function -
Two-way switch
Voltage type -
AC
Width in number of modular spacings -
1

Availability On Request

£87.40
