5TT44115

Remote switch contact for 20 A voltage 24 V DC 1 NO

Manufacturer's No: 5TT4411-5     Manufacturer: Siemens
Remote switch contact for 20 A voltage 24 V DC 1 NO

Availability On Request

£56.32
  • Remote control switch
  • Contact rating: 20 A
  • Voltage: 24 V DC
  • Contact configuration: 1 NO

Accessories



Product

Manufacturer Material ID -
5TT4411-5
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
SI
Export Control Regulations -
AL: N / ECCN: N
UNSPSC -
39121601

Technical Specification

Built-in depth -
73 Millimetre
Type of control voltage 2 -
AC/DC
Manual operation possible -
Control voltage 1 -
207 Volt
Function -
Mechanical switch
Manual operation -
Max. incandescent lamp load -
4400 Watt
Max. load fluorescent lamp -
1102 Voltampere
Max. load fluorescent lamp (Duo circuit) -
2436 Voltampere
Max. load fluorescent lamp (parallel compensated) -
812 Voltampere
Max. switching current (cos phi = 0.6) -
20 Ampere
Mounting method -
DIN rail
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
0
Number of contacts as normally open contact -
1
Rated switch current -
20 Ampere
Recess depth -
73 Millimetre
Supply voltage -
230 Volt
Type of control voltage 1 -
DC
Voltage type of supply voltage -
AC
Width in number of modular spacings -
1

Availability On Request

£56.32
