5TT44355

Remote switch contact for 25 A voltage 24 V DC 1 NO 1 NC

Manufacturer's No: 5TT4435-5     Manufacturer: Siemens
Remote switch contact for 25 A voltage 24 V DC 1 NO 1 NC

Availability On Request

£104.90
  • Remote control switch
  • Contact rating: 25 A
  • Voltage: 24 V DC
  • Configuration: 1 NO (Normally Open), 1 NC (Normally Closed)

Accessories



Product

Manufacturer Material ID -
5TT4435-5
Net Weight -
0.23kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
SI
Export Control Regulations -
AL: N / ECCN: N
UNSPSC -
39121601

Technical Specification

Built-in depth -
73 Millimetre
Type of control voltage 2 -
AC/DC
Manual operation possible -
Control voltage 1 -
207 Volt
Function -
Mechanical switch
Manual operation -
Max. incandescent lamp load -
5500 Watt
Max. load fluorescent lamp -
1624 Voltampere
Max. load fluorescent lamp (Duo circuit) -
2436 Voltampere
Max. load fluorescent lamp (parallel compensated) -
986 Voltampere
Max. switching current (cos phi = 0.6) -
25 Ampere
Mounting method -
DIN rail
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Rated switch current -
25 Ampere
Recess depth -
73 Millimetre
Supply voltage -
230 Volt
Type of control voltage 1 -
DC
Voltage type of supply voltage -
AC
Width in number of modular spacings -
1
