6AV66461BA180NA0

SIMATIC HMI ITC1900 V3 neutral design Built-in unit

Manufacturer's No: 6AV6646-1BA18-0NA0     Manufacturer: Siemens
SIMATIC HMI ITC1900 V3 neutral design Built-in unit

Availability On Request

POA
  • SIMATIC ITC1900 V3 Industrial Thin Client
  • 19" widescreen TFT display with capacitive touch sensor
  • Supported protocols: RDP, VNC, SMARTSERVER HTML5
  • Neutral design with panel mount

Accessories

Follow-up article



Product

Manufacturer Material ID -
6AV6646-1BA18-0NA0
Net Weight -
7.26kg

Additional Product Information

Commodity Code -
85371098
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: 5D992
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
32151705

Technical Specification

Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Degree of protection (NEMA) -
UN
Built-in depth -
73 Millimetre
Operation temperature -
0 Degrees celsius
Number of interfaces PROFINET -
2
Front build in possible -
STATFLAG -
B
Number of HW-interfaces Wireless -
0
Preinstalled operating system -
None
Type of display -
TFT
Degree of protection (IP), front side -
IP65
Front built-in possible -
Height of the front -
294 Millimetre
Max. main memory -
512 Megabyte
Number of buttons with LED -
0
Number of free AGP-slots -
0
Number of free ISA-slots -
0
Number of free PCI-slots -
0
Number of free PCMCIA-slots -
0
Number of function buttons -
0
Number of HW-interfaces industrial Ethernet -
2
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
2
Number of HW-interfaces PS2 -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces SCSI -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
4
Number of pixels, horizontal -
1366
Number of pixels, vertical -
768
Number of system buttons -
0
Operating temperature -
0 Degrees celsius
Rack-assembly possible -
Recess depth -
73 Millimetre
Screen diagonal -
18.5 inch
Supply voltage DC -
19.2 Volt
Supporting protocol for other bus systems -
Voltage type of supply voltage -
DC
Width of the front -
464 Millimetre
With hard disc -
With touch screen -
