6AV78632MB100AA0

SIMATIC IFP1500 (1366 x 768) 15" Multi-touch, Extended Version(30M), 24vdc/100-240VAC, DisplayPort/DVI incl. Cables.

Manufacturer's No: 6AV7863-2MB10-0AA0     Manufacturer: Siemens
SIMATIC IFP1500 (1366 x 768) 15" Multi-touch, Extended Version(30M), 24vdc/100-240VAC, DisplayPort/DVI incl. Cables.

Availability On Request

POA
  • Display: 15" SIMATIC IFP1500 Flat Panel
  • Resolution: 1366 x 768 pixels
  • Touchscreen: Multi-touch capability
  • Extended Version: Up to 30 meters
  • Power Input: 24 V DC and 100-240 V AC
  • Interface: DisplayPort/DVI
  • Included Cables: DVI/USB cable (1.8 meters)


Product

Manufacturer Material ID -
6AV7863-2MB10-0AA0
Net Weight -
7.08kg

Additional Product Information

Commodity Code -
85371099
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
43211900

Technical Specification

Horizontal frequency -
- kiloHertz
Frame frequency -
- kiloHertz
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Number of grey-scales/blue-scales of display -
-
Built-in depth -
62.5 Millimetre
Operation temperature -
0 Degrees celsius
Type of display -
TFT
Degree of protection (IP), front side -
IP65
Front built-in possible -
Height of the front -
298 Millimetre
Number of colours of the display -
16777216
Number of function buttons -
0
Number of pixels, horizontal -
1366
Number of pixels, vertical -
768
Operating temperature -
0 Degrees celsius
Recess depth -
62.5 Millimetre
Screen diagonal -
15.6 inch
Supply voltage DC -
19.2 Volt
Voltage type of supply voltage -
DC
Width of the front -
416.5 Millimetre
With colour display -
With HW-interface digital video signal -
With HW-interface USB -
With touch screen -

Availability On Request
