6EP32330TA000AY0

Power supply SITOP PSU3400, 48 V DC/ 24 V DC/10 A

Manufacturer's No: 6EP3233-0TA00-0AY0     Manufacturer: Siemens
Power supply SITOP PSU3400, 48 V DC/ 24 V DC/10 A

Availability On Request

£176.00
  • Model: SITOP PSU3400
  • Input Voltage: 48 V DC (28-60 V)
  • Output Voltage: 24 V DC
  • Output Current: 5 A

Accessories



Product

Manufacturer Material ID -
6EP3233-0TA00-0AY0
Net Weight -
0.38kg

Additional Product Information

Commodity Code -
85044090
Country of Origin -
HU
UNSPSC -
32121704

Technical Specification

Power consumption -
- Voltampere
Width in number of modular spacings -
-
2nd secondary output voltage -
- Volt
3rd secondary output voltage -
- Volt
Rated supply voltage at AC 50 Hz -
- Volt
Rated supply voltage at AC 60 Hz -
- Volt
Performance level acc. EN ISO 13849-1 -
UN
Max. output current 2 -
- Ampere
Max. output current 3 -
- Ampere
Nominal value output voltage 2 -
- Volt
Nominal value output voltage 3 -
- Volt
Nominal value output current 2 -
- Ampere
Nominal value output current 3 -
- Ampere
SIL according to IEC 61508 -
UN
Degree of protection (NEMA) -
UN
Built-in height -
200 Millimetre
Built-in width -
32 Millimetre
Degree of protection (IP) -
IP20
1st secondary output voltage -
24 Volt
Degree of protection (IP rating) -
IP20
Depth -
100 Millimetre
Height -
100 Millimetre
Max. output current 1 -
6 Ampere
Modular version -
Nominal value output current 1 -
5 Ampere
Nominal value output voltage 1 -
24 Volt
Output voltage stabilized -
Power output -
130 Watt
Rail mounting possible -
Rated supply voltage at DC -
48 Volt
Recess height -
200 Millimetre
Recess width -
32 Millimetre
Secondary voltage adjustable -
Short-circuit-proof -
Stabilized -
Type of electric connection -
Screw connection
Voltage type of supply voltage -
DC
Width -
32 Millimetre
