6GT28014BA100AX2

SIMATIC RF300 READER RF350R ATEX

Manufacturer's No: 6GT2801-4BA10-0AX2     Manufacturer: Siemens
SIMATIC RF300 READER RF350R ATEX

Availability On Request

£740.42
  • SIMATIC RF300 Reader RF350R (GEN2)
  • RS422 interface (3964R)
  • IP65 rated for protection against dust and water
  • Operating temperature range: -25 to +70°C
  • Compact size: 75 x 75 x 41 mm
  • Compatible with various antennas: ANT 1, 3, 3NO, 8, 12, 18, 30
  • Special variant available for ATEX Zone 3G/3D and IECEx Zone 2/22

Selectable mandatory product

Accessories



Product

Manufacturer Material ID -
6GT2801-4BA10-0AX2
Net Weight -
0.30kg

Additional Product Information

Commodity Code -
84719000
Country of Origin -
DE
UNSPSC -
32151705

Technical Specification

Diameter -
- Millimetre
Number of digital inputs -
-
Number of digital outputs -
-
Radio protocol -
Other
Material housing -
Plastic
Type of electric connection -
Other
Degree of protection (IP) -
Other
Max. transmission rate, reading -
106 kiloBit/second
Max. transmission rate, writing -
106 kiloBit/second
Connection for external antenna -
Depth -
75 Millimetre
Frequency -
13.56 Megahertz
Height -
41 Millimetre
Housing material -
Plastic
Max. transmission range -
140 Millimetre
Type of voltage (input voltage) -
DC
Width -
75 Millimetre

Availability On Request

£740.42
