6SL32101SE238AA0

18.5kW / 38 A, PM340, Filtered, FSD

Manufacturer's No: 6SL3210-1SE23-8AA0     Manufacturer: Siemens
18.5kW / 38 A, PM340, Filtered, FSD

Availability On Request

POA

This product has been superseded by

6SL32101PE238AL0

Please check compatibility before purchasing.

  • Power Output: 18.5 kW / 38 A
  • Model: PM340
  • Input: 3AC 380-480V, 50/60Hz
  • Output: 3AC 38A (18.5 kW)
  • Frame Size: Blocksize
  • Features: FSD, Integrated Line Filter
  • Cooling: Internal Air Cooling
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
6SL3210-1SE23-8AA0
Net Weight -
19.69kg

Additional Product Information

Commodity Code -
85049099
Country of Origin -
DE
Export Control Regulations -
AL: 9I999 / ECCN: EAR99H
Minimum Order Quantity -
1
RoHs Compliance -
YES
UNSPSC -
32121705

Technical Specification

-
Siemens
Number of digital inputs -
-
Number of digital outputs -
-
Number of analogue inputs -
-
Number of analogue outputs -
-
Number of HW-interfaces industrial Ethernet -
-
Number of HW-interfaces RS-232 -
-
Number of HW-interfaces RS-422 -
-
Number of HW-interfaces RS-485 -
-
Number of HW-interfaces serial TTY -
-
Number of HW-interfaces USB -
-
Number of HW-interfaces parallel -
-
Number of HW-interfaces other -
-
Mains frequency -
UN
Number of interfaces PROFINET -
-
Type of converter -
UN
Number of phases output -
UN
Max. output frequency -
- Hertz
Max. output at quadratic load at rated output voltage -
- Kilowatt
Relative symmetric net voltage tolerance -
- Percentage
Relative symmetric net frequency tolerance -
- Percentage
Max. output voltage -
- Volt
Nominal output current I2N -
- Ampere
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
Depth -
203.5 Millimetre
Height -
511 Millimetre
Mains voltage -
380 Volt
Max. output at linear load at rated output voltage -
15 Kilowatt
Number of phases input -
3
Width -
275 Millimetre

Availability On Request

POA
Sign in or Register for customer prices.

This product has been superseded by

6SL32101PE238AL0

Please check compatibility before purchasing.
