6AG19312BA003AA0

SIPLUS PS 24 V/0.375 A Condensation permissible in: 48...220 V DC out: 24 V DC/0.375 A based on 6EP1731-2BA00

Manufacturer's No: 6AG1931-2BA00-3AA0     Manufacturer: Siemens
SIPLUS PS 24 V/0.375 A Condensation permissible in: 48...220 V DC out: 24 V DC/0.375 A based on 6EP1731-2BA00

Availability On Request

POA

This product has been superseded by

6AG13320TA007AY0

Please check compatibility before purchasing.

  • Input voltage range: 48-220 V DC
  • Output voltage: 24 V DC
  • Output current: 0.375 A
  • Model: 6EP1731-2BA00
  • Product cancellation date: 12/01/24
  • Successor model: 6AG1332-0TA00-7AY0
  • Sparepart product

Follow-up article



Product

Manufacturer Material ID -
6AG1931-2BA00-3AA0
Net Weight -
0.17kg

Additional Product Information

Commodity Code -
85044095
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
39121004

Technical Specification

Power consumption -
- Voltampere
Width in number of modular spacings -
-
2nd secondary output voltage -
- Volt
3rd secondary output voltage -
- Volt
Rated supply voltage at AC 50 Hz -
- Volt
Rated supply voltage at AC 60 Hz -
- Volt
Performance level acc. EN ISO 13849-1 -
UN
Max. output current 2 -
- Ampere
Max. output current 3 -
- Ampere
Nominal value output voltage 2 -
- Volt
Nominal value output voltage 3 -
- Volt
Nominal value output current 2 -
- Ampere
Nominal value output current 3 -
- Ampere
SIL according to IEC 61508 -
UN
Degree of protection (NEMA) -
UN
Built-in height -
180 Millimetre
Built-in width -
22.5 Millimetre
Degree of protection (IP) -
IP20
1st secondary output voltage -
24 Volt
Degree of protection (IP rating) -
IP20
Depth -
91 Millimetre
Height -
80 Millimetre
Max. output current 1 -
0.375 Ampere
Modular version -
Nominal value output current 1 -
0.375 Ampere
Nominal value output voltage 1 -
24 Volt
Output voltage stabilized -
Power output -
9 Watt
Rail mounting possible -
Rated supply voltage at DC -
48 Volt
Recess height -
180 Millimetre
Recess width -
22.5 Millimetre
Short-circuit-proof -
Stabilized -
Type of electric connection -
Screw connection
Voltage type of supply voltage -
DC
Width -
22.5 Millimetre
