6AG25111AK014AB0

SIPLUS S7-1500 CPU 1511-1 PN TX RAIL -40 ... +70 °C TX with 85°C for 10 min with conformal coating

Manufacturer's No: 6AG2511-1AK01-4AB0     Manufacturer: Siemens
SIPLUS S7-1500 CPU 1511-1 PN TX RAIL -40 ... +70 °C TX with 85°C for 10 min with conformal coating

Availability On Request

POA

This product has been superseded by

6AG25111AK024AB0

Please check compatibility before purchasing.

  • SIPLUS S7-1500 CPU 1511-1 PN TX RAIL
  • Temperature range: -40°C to +70°C (85°C for 10 min with conformal coating)
  • Central processing unit with 150 KB RAM for program and 1 MB for data
  • 1st interface: PROFINET IRT with 2-PORT SWITCH (60 ns bit performance)
  • SIMATIC Memory Card required (no display)


Product

Manufacturer Material ID -
6AG2511-1AK01-4AB0
Net Weight -
0.51kg

Additional Product Information

Commodity Code -
85371091
Country of Origin -
DE
Export Control Regulations -
EAR99H / N
Minimum Order Quantity -
1
UNSPSC -
43201503

Technical Specification

Category according to EN 954-1 -
UN
Max. number of time switches -
-
Performance level acc. EN ISO 13849-1 -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
SIL according to IEC 61508 -
UN
Width -
70 Millimetre
Model -
Modular
Height -
147 Millimetre
Depth -
129 Millimetre
Number of digital inputs -
0
Number of digital outputs -
0
Number of analogue inputs -
0
Number of analogue outputs -
0
Voltage type of supply voltage -
DC
Type of memory -
Other
Memory size -
1150 kiloByte (1000 Byte)
Processing time (1K, binary operation) -
0.06 Millisecond
Number of HW-interfaces industrial Ethernet -
1
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces other -
0
Supporting protocol for TCP/IP -
Supporting protocol for MODBUS -
Rail mounting possible -
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Explosion safety category for dust -
None
System accessory -
Number of interfaces PROFINET -
1
Number of HW-interfaces Wireless -
0
Number of relay outputs -
0
Supporting protocol for PROFINET IO -
Supply voltage DC -
19.2 Volt
-
- SIPLUS S7-1500 CPU 1511-1 PN TX RAIL - Temperature range: -40°C to +70°C (85°C for 10 min with conformal coating) - Central processing unit with 150 KB RAM for program and 1 MB for data - 1st interface: PROFINET IRT with 2-PORT SWITCH (60 ns bit performance) - SIMATIC Memory Card required (no display)

Availability On Request

POA
Sign in or Register for customer prices.

This product has been superseded by

6AG25111AK024AB0

Please check compatibility before purchasing.
