6EP33343SB000AX0

SITOP PSU4200 1AC 24 V/10 A stabilized power supply PSU4200 input: 120/240 V AC output: 24 V DC/ 10 A

Manufacturer's No: 6EP3334-3SB00-0AX0     Manufacturer: Siemens

Availability Back Order

£122.00
  • Model: SITOP PSU4200
  • Input Voltage: 120/240 V AC
  • Output Voltage: 24 V DC
  • Output Current: 10 A
  • Stabilized power supply


Product

Manufacturer Material ID -
6EP3334-3SB00-0AX0
Net Weight -
0.83kg

Additional Product Information

Commodity Code -
85044083
Country of Origin -
RO
Export Control Regulations -
N / N
UNSPSC -
32121704

Technical Specification

1st secondary output voltage -
24 Volt
Degree of protection (IP rating) -
IP20
Depth -
125 Millimetre
Direct mounting possible -
Height -
135 Millimetre
Max. output current 1 -
10 Ampere
Modular version -
Nominal value output current 1 -
10 Ampere
Nominal value output voltage 1 -
24 Volt
Output voltage stabilized -
Power output -
240 Watt
Rail mounting possible -
Rated supply voltage at AC 50 Hz -
240 Volt
Rated supply voltage at AC 60 Hz -
120 Volt
Recess height -
225 Millimetre
Recess width -
70 Millimetre
Secondary voltage adjustable -
Short-circuit-proof -
Stabilized -
Voltage type of supply voltage -
AC
Wall mounting possible -
Width -
70 Millimetre

Availability Back Order

£122.00
