6ES73325TB100AB0

SIMATIC DP, HART ANALOG OUTPUT

Manufacturer's No: 6ES7332-5TB10-0AB0     Manufacturer: Siemens
SIMATIC DP, HART ANALOG OUTPUT

Availability On Request

POA
SIMATIC DP, HART analog output, SM 332, 2 AO, 0/4 - 20 mA HART, as of HART Rev. 5.0, for ET200M with IM 153-2, 1 x 20-pole The SIMATIC ET 200M is a modular and universally applicable I/O system for the control cabinet in IP20, which can be used as a central I/O on an S7-300 as well as in a distributed configuration on a PROFINET or PROFIBUS ET 200M interface module. As many as 12 IO modules can be inserted into each station. The standardized setup of all modules considerably simplifies logistics and stocking of spare parts. The ET 200M can be used both for standard and for safety-oriented applications. Up to 12 multi-channel signal modules (e.g. 64 digital inputs) and function modules as well as S7-300 communications processors can be used as I/O modules (the interface to the process). This means the ET 200M also supports modules with extended user data, such as HART modules with HART auxiliary variables. In addition to conventional connection methods, the ET 200M offers you the FastConnect fast connection technology for easy wiring without stripping.
Product video


Product

Manufacturer Material ID -
6ES7332-5TB10-0AB0
Net Weight -
0.33kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
32151705

Technical Specification

Resolution of the analogue inputs -
- Bit
Type of electric connection -
UN
Explosion safety category for gas -
UN
Explosion safety category for dust -
UN
Category according to EN 954-1 -
UN
Number of interfaces PROFINET -
-
Performance level acc. EN ISO 13849-1 -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Supply voltage DC -
- Volt
SIL according to IEC 61508 -
UN
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
Analogue outputs configurable -
Degree of protection (IP rating) -
IP20
Depth -
120 Millimetre
Height -
125 Millimetre
Number of analogue inputs -
0
Number of analogue outputs -
2
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces Wireless -
0
Output signal configurable -
Rack-assembly possible -
Resolution of the analogue outputs -
12 Bit
System accessory -
Voltage type of supply voltage -
DC
Width -
40 Millimetre

Availability On Request

POA
