6ES76772FA310EB0

CPU 1515SP PC F

Manufacturer's No: 6ES7677-2FA31-0EB0     Manufacturer: Siemens
CPU 1515SP PC F

Availability On Request

POA
  • CPU 1515SP PC F with 4 GB RAM and 30 GB CFAST storage
  • Pre-installed with WES 7 E 32 bit and S7-1500 Fail-safe SWC CPU 1505SP F
  • Interfaces: 1x CFAST slot, 1x SD/MMC slot, 1x ET 200SP bus adapter connection, 1x 10/100/1000 Mbit/s Ethernet, 3x USB, 1x DVI-I graphics card connection
  • Documentation provided on DVD, Restore DVD included

  • SIMATIC ET 200SP: multifunctional IO system for various applications

  • Scalable design for compact control cabinet installation
  • Supports multiple communication protocols with high speed and transmission rates
  • Direct connection option for 2, 3, or 4-wire sensors/actuators

  • SIMATIC ET 200SP Open Controller: combines PC-based software controller, visualization, and central I/Os in a single device

  • Available in fail-safe design and with HMI functionality

Selectable mandatory product

Product video


Product

Manufacturer Material ID -
6ES7677-2FA31-0EB0
Net Weight -
1.08kg

Additional Product Information

Commodity Code -
85371091
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
43201503

Technical Specification

Type of electric connection -
UN
Category according to EN 954-1 -
UN
Output voltage at AC 50 Hz -
- Volt
Output voltage at AC 60 Hz -
- Volt
Output voltage at DC -
- Volt
Input voltage at AC 50 Hz -
- Volt
Input voltage at AC 60 Hz -
- Volt
Max. output current AC 50 Hz -
- Ampere
Max. output current AC 60 Hz -
- Ampere
Max. output current DC -
- Ampere
Max. input current AC 50 Hz -
- Ampere
Max. input current AC 60 Hz -
- Ampere
Max. input current DC -
- Ampere
Type of output voltage -
UN
With bus coupler for modular station connection -
Degree of protection (IP) -
IP20
Number of interfaces PROFINET -
1
Performance level acc. EN ISO 13849-1 -
Level e
SIL according to IEC 61508 -
3
Bus coupler for modular station connection available -
Degree of protection (IP rating) -
IP20
Depth -
75 Millimetre
Explosion safety category for dust -
None
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Fieldbus connection over separate bus coupler possible -
Height -
117 Millimetre
Input voltage at DC -
19.2 Volt
Number of HW-interfaces industrial Ethernet -
2
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
1
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
1
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
3
Number of HW-interfaces Wireless -
0
Number of slots -
64
Rail mounting possible -
Suitable for safety functions -
Supporting protocol for MODBUS -
Supporting protocol for PROFIBUS -
Supporting protocol for PROFINET IO -
Supporting protocol for PROFIsafe -
Supporting protocol for TCP/IP -
System accessory -
Type of voltage (input voltage) -
DC
Wall mounting/direct mounting -
Width -
160 Millimetre
With integrated power supply -
With pluggable modules, analogue I/O -
With pluggable modules, central modules -
With pluggable modules, communication modules -
With pluggable modules, digital I/O -
With pluggable modules, function and technology modules -
With pluggable modules, others -
