6GT28012BA100AX2

SIMATIC RF300 reader RF340R (GEN2), RS422 (3964R), IP67, -25 to +70 °C

Manufacturer's No: 6GT2801-2BA10-0AX2     Manufacturer: Siemens
SIMATIC RF300 reader RF340R (GEN2), RS422 (3964R), IP67, -25 to +70 °C

Availability On Request

£733.37
  • SIMATIC RF300 Reader RF340R (GEN2)
  • RS422 interface (3964R)
  • IP67 rated for dust and water resistance
  • Operating temperature range: -25 to +70°C
  • Compact size: 75 x 75 x 41 mm
  • Integrated antenna
  • Special variant ATEX certified for Zone 3G/3D and IECEx certified for Zone 2/22

Selectable mandatory product



Product

Manufacturer Material ID -
6GT2801-2BA10-0AX2
Net Weight -
0.30kg

Additional Product Information

Commodity Code -
84719000
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
32151705

Technical Specification

Diameter -
- Millimetre
Number of digital inputs -
-
Number of digital outputs -
-
Material housing -
Plastic
Degree of protection (IP) -
Other
Radio protocol -
Other
Type of electric connection -
Screw connection
Degree of protection (IP rating) -
Other
Max. transmission rate, reading -
106000 kiloBit/second
Max. transmission rate, writing -
106000 kiloBit/second
Depth -
75 Millimetre
Frequency -
13.56 Megahertz
Height -
41 Millimetre
Housing material -
Plastic
Max. transmission range -
140 Millimetre
Type of voltage (input voltage) -
DC
Width -
75 Millimetre
