6SL32440BB001BA1

SINAMICS G120 Control Unit CU240B-2 B type RS485 interface with USS/MODBUS RTU protocol 4 DI, 1 DO,

Manufacturer's No: 6SL3244-0BB00-1BA1     Manufacturer: Siemens
SINAMICS G120 Control Unit CU240B-2 B type RS485 interface with USS/MODBUS RTU protocol 4 DI, 1 DO,

Availability Back Order

POA

This product has been superseded by

6SL32440BB121BA1

Please check compatibility before purchasing.

  • SINAMICS G120 Control Unit CU240B-2 B type
  • RS485 interface with USS/MODBUS RTU protocol
  • 4 digital inputs (DI)
  • 1 digital output (DO)
  • 1 analog input (AI)
  • 1 analog output (AO)
  • PTC/KTY/Thermoclick Interface
  • USB and SD/MMC interface
  • Degree of protection: IP20
  • Ambient temperature: 0 to +50°C (without Power Module)
Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
6SL3244-0BB00-1BA1
Net Weight -
0.50kg

Additional Product Information

Commodity Code -
85049099
Country of Origin -
GB
Export Control Regulations -
N / 9I999IR
Minimum Order Quantity -
1
UNSPSC -
32121704

Technical Specification

Number of HW-interfaces other -
-
Degree of protection (IP) -
UN
Mains voltage -
- Volt
Mains frequency -
UN
Type of converter -
UN
Number of phases output -
UN
Number of phases input -
UN
Max. output frequency -
- Hertz
Max. output at linear load at rated output voltage -
- Kilowatt
Max. output at quadratic load at rated output voltage -
- Kilowatt
Relative symmetric net voltage tolerance -
- Percentage
Relative symmetric net frequency tolerance -
- Percentage
Max. output voltage -
- Volt
Nominal output current I2N -
- Ampere
Number of interfaces PROFINET -
0
Degree of protection (NEMA) -
1
Depth -
46 Millimetre
Height -
199 Millimetre
Number of analogue inputs -
1
Number of analogue outputs -
1
Number of digital inputs -
4
Number of digital outputs -
1
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
1
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
2
Number of HW-interfaces USB -
1
Supporting protocol for MODBUS -
Width -
73 Millimetre
With PC connection -

Availability Back Order

POA
Sign in or Register for customer prices.

This product has been superseded by

6SL32440BB121BA1

Please check compatibility before purchasing.
