6SL33211TE412AA0

SINAMICS S120 Chassis-2 Motor Modules Input: 510-720 V DC Output: 0-480V 3 AC, 1200 A Type rating: 630 kW Built-in unit IP00 Inter

Manufacturer's No: 6SL3321-1TE41-2AA0     Manufacturer: Siemens
SINAMICS S120 Chassis-2 Motor Modules Input: 510-720 V DC Output: 0-480V 3 AC, 1200 A Type rating: 630 kW Built-in unit IP00 Internal air cooling

Availability On Request

POA
  • SINAMICS S120 Chassis-2 Motor Modules
  • Input: 510-720 V DC
  • Output: 0-480V 3 AC, 1200 A
  • Type Rating: 630 kW
  • Built-in Unit: IP00
  • Internal Air Cooling


Product

Manufacturer Material ID -
6SL3321-1TE41-2AA0
Net Weight -
183.00kg

Additional Product Information

Commodity Code -
85044088
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: 9N9999
RoHs Compliance -
Yes
UNSPSC -
39121007

Technical Specification

Number of digital inputs -
-
Number of digital outputs -
-
Number of analogue inputs -
-
Number of analogue outputs -
-
Number of HW-interfaces industrial Ethernet -
-
Number of HW-interfaces RS-232 -
-
Number of HW-interfaces RS-422 -
-
Number of HW-interfaces RS-485 -
-
Number of HW-interfaces serial TTY -
-
Number of HW-interfaces USB -
-
Number of HW-interfaces parallel -
-
Number of HW-interfaces other -
-
Mains frequency -
UN
Number of interfaces PROFINET -
-
Type of converter -
UN
Number of phases output -
UN
Max. output at quadratic load at rated output voltage -
- Kilowatt
Relative symmetric net voltage tolerance -
- Percentage
Relative symmetric net frequency tolerance -
- Percentage
Max. output voltage -
- Volt
Nominal output current I2N -
- Ampere
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP00
Degree of protection (IP rating) -
IP00
Depth -
542 Millimetre
Height -
1491 Millimetre
Mains voltage -
380 Volt
Max. output at linear load at rated output voltage -
560 Kilowatt
Max. output frequency -
550 Hertz
Number of phases input -
3
Width -
280 Millimetre

Availability On Request

POA
