6XV18402R

IE TP Robot cable GP;2 x without;2x2;Cat5e;torsion;PUR;robust

Manufacturer's No: 6XV1840-2R     Manufacturer: Siemens
IE TP Robot cable GP;2 x without;2x2;Cat5e;torsion;PUR;robust

Availability On Request

£11.00
  • Product Name: IE TP Robot Cable GP 2x2 (PROFINET type R)
  • Cable Type: TP installation cable
  • Core: 4-core
  • Shielding: Shielded Cat5e
  • Application: Highly flexible applications (torsion, cable carriers)
  • Length: Sold by the meter, maximum 1000m
  • Minimum Order Quantity: 20m

Accessories



Product

Manufacturer Material ID -
6XV1840-2R
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85444920
Country of Origin -
DE
UNSPSC -
26121629

Technical Specification

Category -
5E
Conductor Diameter -
0.74 Millimetre
Conductor surface -
Bare
Core identification -
Colour
Individual screen type -
None
Number of cores -
4
Number of stranding elements -
2
NVP value -
69 Percentage
Outer diameter approx. -
6.5 Millimetre
Overall screen type -
Foil + braiding
Permitted cable outer temperature after assembling without vibration -
0 Degrees celsius
Permitted cable outer temperature during assembling/handling -
-20 Degrees celsius
Reaction-to-fire according to EN 13501-6: Class -
Eca
Sheath colour -
Green
Stranding element -
Quad

Availability On Request

£11.00
