6XV18762B

IE FC TP flexible cable GP 4x2, AWG 24, CAT7, sold by the meter, min. 20 m

Manufacturer's No: 6XV1876-2B     Manufacturer: Siemens
IE FC TP flexible cable GP 4x2, AWG 24, CAT7, sold by the meter, min. 20 m

Availability On Request

£5.00
  • Type: Flexible Cable
  • Application: CAT7 cable for IE FC RJ45 plug 4x2 and IE FC M12 plug PRO 4x2
  • Configuration: 4 pairs, AWG26
  • FastConnect technology
  • Sold by the meter
  • Delivery unit: max. 3000 m
  • Minimum order quantity: 20 m

Accessories



Product

Manufacturer Material ID -
6XV1876-2B
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85444920
Country of Origin -
DE
UNSPSC -
26121629

Technical Specification

Category -
7
Conductor Diameter -
0.47 Millimetre
Conductor surface -
Bare
Core identification -
Colour
Individual screen type -
None
Min. permitted bending radius, moving application with forced guidance -
80 Millimetre
Min. permitted bending radius, moving application/free movement -
80 Millimetre
Min. permitted bending radius, stationary application/permanent installation -
80 Millimetre
Number of cores -
8
Number of stranding elements -
4
NVP value -
69 Percentage
Outer diameter approx. -
8 Millimetre
Overall screen type -
Foil + braiding
Permitted cable outer temperature after assembling without vibration -
-30 Degrees celsius
Permitted cable outer temperature during assembling/handling -
-30 Degrees celsius
Reaction-to-fire according to EN 13501-6: Class -
Eca
Sheath colour -
Green
Stranding element -
Pairs

Availability On Request

£5.00
