722-141/047-000

THT female header, straight, Pin spacing 5 mm, 11-pole, 100% protected against mismating, Spacer fla

Manufacturer's No: 722-141/047-000     Manufacturer: WAGO
THT female header, straight, Pin spacing 5 mm, 11-pole, 100% protected against mismating, Spacer fla

Availability Back Order

POA
  • THT female header
  • Straight design
  • Pin spacing: 5 mm
  • 11-pole configuration
  • 100% protected against mismating
  • Spacer flange included
  • Solder pin dimensions: 0.6 x 1.0 mm
  • Color: Light gray

Accessories

Screw with nut, M2x12, for fixing element

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 231-195
Price £0.08
Back Order

Self-Tapping Screw,

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 209-147
Price £0.07
Back Order

Self-tapping screw, B 2.2x13, fixing hole 1.8 mm dia

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 231-194
Price £0.07
Back Order


Product

Manufacturer Material ID -
722-141/047-000
Net Weight -
0.47kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Diameter connection pin -
- Millimetre
Colour housing -
Other
Operation temperature -
-60 Degrees celsius
Angle PCB/contact -
90° (upwards vertical)
Connector model -
Free connector
Contact type -
Pin
Housing colour -
Other
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
5 Millimetre
Material insulation body -
Thermoplastic
Material of contact surface -
Tin
Modular spacing connections -
5 Millimetre
Modular spacing contacts -
5 Millimetre
Number of plug-in contact rows -
1
Number of poles -
11
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
12 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
320 Volt
Suitable for PCB thickness -
1.5 Millimetre
Type of banding -
None
Type of connection -
Flexible PCB-connector
Type of electric connection -
Soldering connection
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact
