734-510

THT female header; 0.9 x 0.9 mm solder pin; straight; 100% protected against mismating; Pin spacing 3.81 mm; 10-pole

Manufacturer's No: 734-510     Manufacturer: WAGO
THT female header; 0.9 x 0.9 mm solder pin; straight; 100% protected against mismating; Pin spacing 3.81 mm; 10-pole

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£4.98
  • THT female header
  • Straight design
  • Pin spacing: 3.81 mm
  • 10-pole configuration
  • 100% protected against mismating
  • Solder pin size: 0.9 x 0.9 mm
  • Color: Orange

Male Connector, 10-Pole Pin Spacing 3.81 mm / 0.15 In Orange

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 734-340
Price £6.21
Back Order


Product

Manufacturer Material ID -
734-510
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
85366990
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Diameter connection pin -
- Millimetre
Colour housing -
Orange
Operation temperature -
-60 Degrees celsius
Angle PCB/contact -
90° (upwards vertical)
Connector model -
Free connector
Contact type -
Pin
Housing colour -
Orange
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
3.8 Millimetre
Material insulation body -
Thermoplastic
Material of contact surface -
Tin
Modular spacing connections -
3.81 Millimetre
Modular spacing contacts -
3.81 Millimetre
Number of plug-in contact rows -
1
Number of poles -
10
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
10 Ampere
Rated surge voltage -
2.5 Kilovolt
Rated voltage -
160 Volt
Suitable for PCB thickness -
5 Millimetre
Type of banding -
None
Type of connection -
Flexible PCB-connector
Type of electric connection -
Soldering connection
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£4.98
