770-1608

h-distribution connector with high-voltage symbol, black for 5 terminal blocks, yellow

Manufacturer's No: 770-1608     Manufacturer: WAGO
h-distribution connector with high-voltage symbol, black for 5 terminal blocks, yellow

Availability Back Order

POA
  • H-distribution connector
  • 2-pole
  • Cod. B
  • 1 input, 2 outputs on both sides
  • 2 locking levers
  • Color: Gray

Accessories

Mounting plate, 2-pole, for distribution connectors, Plastic, black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 770-1626
Price £0.34
Back Order

Mounting plate, 2-pole, for distribution connectors, Plastic, white

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 770-1627
Price £0.34
Back Order

Lockout cap, 12-pole, separable, for sockets, Plastic, black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 770-201
Price £0.44
Back Order

Lockout cap, 12-pole, separable, for sockets, Plastic, white

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 770-221
Price £0.44
Back Order

Lockout cap, for plugs, 5-pole, separable, yellow

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 770-360
Price £0.68
Back Order


Product

Manufacturer Material ID -
770-1608
Net Weight -
0.80kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Phase pickup -
UN
Locking mechanism -
Integrated in plug-in connector
Material housing -
Polyamide (PA)
Continuity resistor -
0.5 Milli-Ohm
Degree of protection (IP) -
IP20
Colour coding/contact insert -
Grey
Colour of the separate adapter piece -
Without adapter piece
Contact material -
CuSn
Continuity resistance -
1 Milli-Ohm
Degree of protection (IP rating) -
IP20
Fire load -
0.06889 Kilowatthour
Halogen free -
Height -
32.7 Millimetre
Housing material -
Polyamide (PA)
Length -
45.8 Millimetre
Max. continuous temperature resistance contact part -
85 Degrees celsius
Max. continuous temperature resistance strain relief -
105 Degrees celsius
Mechanical coding -
Mounting possibility -
With separate adapter
Number of inputs -
2
Number of outputs -
4
Number of poles -
2
Pole codification -
1, 2
Pollution degree -
3
Rated current -
25 Ampere
Rated current to luminaire -
25 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
250 Volt
Surface finish contacts -
Tinned
Type of distributor -
Distribution terminal block
Type of integrated switching -
None
Type of locking -
Integrated in plug-in connector
Width -
20 Millimetre

Availability Back Order

POA
