774-9973/216-505

pre-assembled connecting cable, Eca, Plug/open-ended, brown

Manufacturer's No: 774-9973/216-505     Manufacturer: WAGO
pre-assembled connecting cable, Eca, Plug/open-ended, brown

Availability Back Order

POA
  • Pre-assembled connecting cable
  • Eca rated
  • Plug/open-ended with 3-pole configuration
  • Cable type: H05Z1Z1-F
  • Conductor size: 3x1.5 mm²
  • Cable length: 5 meters
  • Conductor size: 1.5 mm²
  • Color: Brown


Product

Manufacturer Material ID -
774-9973/216-505
Net Weight -
0.49kg

Additional Product Information

Commodity Code -
85444290
Country of Origin -
DE
UNSPSC -
39121410

Technical Specification

Cable diameter -
7.4 Millimetre
Cable permanent temperature-resistant to -
70 Degrees celsius
Cable type -
H05Z1Z1-F
Colour coding/contact insert -
Brown
Conductor end treatment -
Ultrasonic compressed wire ends
Contact material -
CuSn
Continuity resistance -
1 Milli-Ohm
Degree of protection (IP rating) -
IP20
Dismantle length -
100 Millimetre
Fire load -
41.379368 Kilowatthour
Halogen free -
Housing colour -
Black
Housing material -
Polyamide (PA)
Insulating piece permanent temperature-resistant -
105 Degrees celsius
Max. operation temperature at conductor -
85 Degrees celsius
Mechanical coding -
Nominal cross sectional area of conductor -
1.5 Square millimetre
Number of poles -
3
Pole codification -
Other
Pollution degree -
3
Rated current -
16 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
250 Volt
Reaction-to-fire according to EN 13501-6: Class -
Eca
Sheath colour -
Black
Strip length -
11 Millimetre
Surface finish contacts -
Tinned
Total length -
5000 Millimetre
Type of finished cable -
Other
Type of locking -
Separate
Type side 1 -
Plug
Type side 2 -
Free conductor end

Availability Back Order

POA
