7MF03011JD015AF2-Z A00+E01

SITRANS P320 Pressure transmitter Gauge pressure PROFIBUS PA Measuring cell filling: Silicone oil Maximum measuring span: 1000 mba

Manufacturer's No: 7MF0301-1JD01-5AF2-ZA00+E01     Manufacturer: Siemens
SITRANS P320 Pressure transmitter Gauge pressure PROFIBUS PA Measuring cell filling: Silicone oil Maximum measuring span: 1000 mbar (14.5 psi) Male thread G1/2B (DIN EN 837-1) Diaphragm: Stainless ste

Availability Back Order

£1,678.00
  • Pressure transmitter for gauge pressure measurement
  • Measuring cell filling: Silicone oil
  • Maximum measuring span: 1000 mbar (14.5 psi)
  • Male thread G1/2 (DIN EN 837-1)
  • Process connection: Stainless steel 316L/1.4404
  • Seal diaphragms: Stainless steel 316L/1.4404
  • Sensor differential pressure: Process flange: Stainless steel 316/1.4408
  • Die-cast aluminum housing
  • Dual chamber device
  • With display (lid with glass window)

Read more

  • Cable gland and sealing plug attached, plastic
  • General approval without Ex approval: World (CE, UKCA, RCM, CSA, EAC, FM, KC)


Product

Manufacturer Material ID -
7MF0301-1JD01-5AF2-ZA00+E01
Net Weight -
1.80kg

Additional Product Information

Commodity Code -
90262020
Country of Origin -
FR
Export Control Regulations -
3A991X / N
UNSPSC -
32151705

Availability Back Order

£1,678.00
