893-2032

Snap-in plug, 2-pole, Cod. F, light gray

Manufacturer's No: 893-2032     Manufacturer: WAGO
Snap-in plug, 2-pole, Cod. F, light gray

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.50

£5.75
  • Snap-in plug
  • 2-pole
  • Cod. F
  • Light gray


Product

Manufacturer Material ID -
893-2032
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
85366990
Country of Origin -
CH
Minimum Order Quantity -
50
UNSPSC -
39121402

Technical Specification

Connection cross section (fine-strand) -
- Square millimetre
Connection cross section (solid-core) -
- Square millimetre
Length soldering pin -
- Millimetre
Wall thickness housing -
- Millimetre
Colour housing -
Black
Locking mechanism -
None
Material housing -
Polyamide (PA)
Continuity resistor -
5 Milli-Ohm
Degree of protection (IP) -
IP20
Pole codification -
1+, 2-
Colour coding/contact insert -
Grey
Angle of inclination -
0 Degrees
Angle of plug -
Straight
Built-in version -
Snap-in/screw-in device
Colour of the separate adapter piece -
Without adapter piece
Connection size thread -
No thread connection
Connection type -
Spring clamp connection
Contact material -
CuSn
Continuity resistance -
3 Milli-Ohm
Degree of protection (IP rating) -
IP20
Fire load -
0 Kilowatthour
Halogen free -
Height -
19.6 Millimetre
Housing colour -
Black
Housing material -
Polyamide (PA)
Length -
29.5 Millimetre
Max. continuous temperature resistance contact part -
85 Degrees celsius
Max. continuous temperature resistance strain relief -
105 Degrees celsius
Mechanical coding -
Model -
Plug
Number of connections per pole -
1
Number of poles -
2
Pollution degree -
3
Rated current -
3 Ampere
Rated surge voltage -
0.8 Kilovolt
Rated voltage -
50 Volt
Surface finish contacts -
Tinned
Type of locking -
None
Width -
19.6 Millimetre
