899-632/103-000

Distribution box, Surge switch circuit, 2 inputs, black

Manufacturer's No: 899-632/103-000     Manufacturer: WAGO
Distribution box, Surge switch circuit, 2 inputs, black

Availability On Request

POA
  • Distribution box with surge switch circuit
  • 2 inputs and 2 outputs
  • Features Cod. A and MIDI connectivity
  • Color: black


Product

Manufacturer Material ID -
899-632/103-000
Net Weight -
0.68kg

Additional Product Information

Commodity Code -
85366990
Country of Origin -
DE
UNSPSC -
39121410

Technical Specification

Colour coding/contact insert -
Multi colour
Colour of the separate adapter piece -
Without adapter piece
Contact material -
Other
Continuity resistance -
1 Milli-Ohm
Degree of protection (IP rating) -
IP20
Fire load -
3.66611 Kilowatthour
Halogen free -
Height -
30 Millimetre
Housing material -
Polyamide (PA)
Length -
190 Millimetre
Max. continuous temperature resistance contact part -
85 Degrees celsius
Max. continuous temperature resistance strain relief -
105 Degrees celsius
Mechanical coding -
Mounting possibility -
With separate adapter
Number of inputs -
2
Number of outputs -
2
Number of poles -
3
Phase pickup -
L1
Pollution degree -
3
Rated current -
16 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
250 Volt
Surface finish contacts -
Tinned
Type of distributor -
Distribution terminal block
Type of integrated switching -
None
Type of locking -
Integrated in plug-in connector
Width -
145 Millimetre
