899-681

Distribution box, for self-assembly, white

Manufacturer's No: 899-681     Manufacturer: WAGO
Distribution box, for self-assembly, white

Availability On Request

£18.59
  • Distribution box for self-assembly
  • Color: White


Product

Manufacturer Material ID -
899-681
Net Weight -
0.25kg

Additional Product Information

Commodity Code -
85366990
Country of Origin -
DE
UNSPSC -
32151903

Technical Specification

Pole codification -
UN
Phase pickup -
UN
Locking mechanism -
Integrated in plug-in connector
Material housing -
Polyamide (PA)
Continuity resistor -
1 Milli-Ohm
Degree of protection (IP) -
IP20
Colour coding/contact insert -
Other
Colour of the separate adapter piece -
Without adapter piece
Contact material -
Other
Continuity resistance -
1 Milli-Ohm
Degree of protection (IP rating) -
IP20
Fire load -
1.49 Kilowatthour
Halogen free -
Height -
30 Millimetre
Housing material -
Polyamide (PA)
Length -
190 Millimetre
Max. continuous temperature resistance contact part -
85 Degrees celsius
Max. continuous temperature resistance strain relief -
105 Degrees celsius
Mechanical coding -
Mounting possibility -
With separate adapter
Number of inputs -
0
Number of outputs -
0
Number of poles -
3
Pollution degree -
3
Rated current -
25 Ampere
Rated current to luminaire -
25 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
250 Volt
Surface finish contacts -
Other
Type of distributor -
Distribution terminal block
Type of integrated switching -
None
Type of locking -
Integrated in plug-in connector
Width -
145 Millimetre

Availability On Request

£18.59
