899-681/144-000

Distribution box, Three-phase to single-phase current (400 V/230 V), 2 inputs, white

Manufacturer's No: 899-681/144-000     Manufacturer: WAGO
Distribution box, Three-phase to single-phase current (400 V/230 V), 2 inputs, white

Availability On Request

POA
  • Distribution box for converting three-phase to single-phase current (400 V/230 V)
  • 2 inputs and 6 outputs
  • Cod. A model
  • MIDI compatible
  • Color: white


Product

Manufacturer Material ID -
899-681/144-000
Net Weight -
0.42kg

Additional Product Information

Commodity Code -
85366990
Country of Origin -
DE
UNSPSC -
39121410

Technical Specification

Colour coding/contact insert -
White
Colour of the separate adapter piece -
Without adapter piece
Contact material -
Other
Continuity resistance -
1 Milli-Ohm
Degree of protection (IP rating) -
IP20
Fire load -
2.97222 Kilowatthour
Halogen free -
Height -
30 Millimetre
Housing material -
Polyamide (PA)
Length -
190 Millimetre
Max. continuous temperature resistance contact part -
85 Degrees celsius
Max. continuous temperature resistance strain relief -
105 Degrees celsius
Mechanical coding -
Mounting possibility -
With separate adapter
Number of inputs -
2
Number of outputs -
6
Phase pickup -
L1-L3
Pollution degree -
3
Rated current -
25 Ampere
Rated surge voltage -
6 Kilovolt
Rated voltage -
400 Volt
Surface finish contacts -
Tinned
Type of distributor -
Distribution terminal block
Type of integrated switching -
Two-way switching
Type of locking -
Integrated in plug-in connector
Width -
145 Millimetre

Availability On Request

POA
