8WA20113KE13

initiator terminals (L+, L-, shield, A) with yellow LED, PNP, 15-30V, spring-l. term., sz 1.5mm2, 5m

Manufacturer's No: 8WA2011-3KE13     Manufacturer: Siemens
initiator terminals (L+, L-, shield, A) with yellow LED, PNP, 15-30V, spring-l. term., sz 1.5mm2, 5m

Availability On Request

POA

This product has been superseded by

8WH60040FE00

Please check compatibility before purchasing.

  • Initiator terminals: L+, L-, shield, A
  • Yellow LED indicator
  • PNP type
  • Operating voltage: 15-30V
  • Spring-loaded terminals
  • Wire size: 1.5mm2
  • Cable length: 5m
  • Product discontinued since: 09/10/23
  • Successor model: 8WH60040FE00


Product

Manufacturer Material ID -
8WA2011-3KE13
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
GR
Export Control Regulations -
N / N
Minimum Order Quantity -
20
UNSPSC -
39121410

Technical Specification

Length -
- Millimetre
Operation temperature -
- Degrees celsius
Height at lowest possible mounting height -
- Millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
- Square millimetre
Width/grid dimension -
5 Millimetre
Connection position -
Above
Colour -
Grey
Colour lamp -
Other
Connectable conductor cross section fine-strand without cable end sleeve -
0.08 Square millimetre
Connectable conductor cross section multi-wired -
0.5 Square millimetre
Connectable conductor cross section solid-core -
0.08 Square millimetre
Inflammability class of insulation material acc. with UL94 -
V2
LED switching for -
PNP
Material insulation body -
Thermoplastic
Mounting method -
DIN rail (top hat rail) 35 mm
Number of clamp positions per level -
1
Number of levels -
5
Rated current In -
10 Ampere
Rated voltage -
64 Volt
Type of electrical connection 1 -
Spring clamp connection
Type of electrical connection 2 -
Spring clamp connection
