8MF18682GS40

SIVACON, Supporting structure, for standard Empty enclosure, H: 1800 mm, W: 600 mm, T: 800 mm, RAL 7035

Manufacturer's No: 8MF1868-2GS40     Manufacturer: Siemens
SIVACON, Supporting structure, for standard Empty enclosure, H: 1800 mm, W: 600 mm, T: 800 mm, RAL 7035

Availability On Request

POA
  • Product Name: SIVACON Supporting Structure
  • Compatible with: Standard Empty Enclosure
  • Height: 1800 mm
  • Width: 600 mm
  • Depth: 800 mm
  • Color: RAL 7035
Presentation video
Presentation video


Product

Manufacturer Material ID -
8MF1868-2GS40
Net Weight -
43.30kg

Additional Product Information

Commodity Code -
94039010
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
RoHs Compliance -
Yes
UNSPSC -
26101601

Technical Specification

Max. load capacity -
- Kilogram
Model -
Other
RAL-number -
7035
Material -
Other
Colour -
Grey
Depth -
800 Millimetre
Height -
1800 Millimetre
Suitable for enclosure building depth -
800 Millimetre
Suitable for enclosure building height -
1800 Millimetre
Suitable for enclosure building width -
600 Millimetre
Width -
600 Millimetre
