8WA10101PH01

PE terminal, blank, size 6 ,1 screw-type terminal

Manufacturer's No: 8WA1010-1PH01     Manufacturer: Siemens
PE terminal, blank, size 6 ,1 screw-type terminal

Availability On Request

POA
  • PE terminal
    • Size: 6
    • Type: Screw-type
    • Bare
  • Screw terminal
    • Size: 6


Product

Manufacturer Material ID -
8WA1010-1PH01
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
GR
Export Control Regulations -
N / N
Minimum Order Quantity -
50
UNSPSC -
39121410

Technical Specification

Length -
51 Millimetre
Operation temperature -
-25 Degrees celsius
Width/grid dimension -
6 Millimetre
Height at lowest possible mounting height -
25 Millimetre
Connection position -
Sideways
Colour -
Other
Connectable conductor cross section fine-strand with cable end sleeve -
6 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
6 Square millimetre
Connectable conductor cross section multi-wired -
6 Square millimetre
Connectable conductor cross section solid-core -
6 Square millimetre
Inflammability class of insulation material acc. with UL94 -
V2
Material insulation body -
None
Mounting method -
DIN rail (top hat rail) 35 mm
Number of clamp positions per level -
1
Number of levels -
1
Operating temperature -
-25 Degrees celsius
Type of electrical connection 1 -
Screw connection
Type of electrical connection 2 -
Screw connection

Availability On Request

POA
