8WH12010AM00

Terminal block for installation terminal, conductor cross-section 35 mm2 color gray

Manufacturer's No: 8WH1201-0AM00     Manufacturer: Siemens
Terminal block for installation terminal, conductor cross-section 35 mm2 color gray

Availability On Request

£12.26
  • Terminal type: Screw terminal
  • Installation type: Through-type terminal
  • Maximum wire size: 35 mm²
  • Color: Gray


Product

Manufacturer Material ID -
8WH1201-0AM00
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121410

Technical Specification

Basic colour -
Grey
Closing plate required -
Connectable conductor cross section fine-strand with cable end sleeve -
0.8 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.75 Square millimetre
Connectable conductor cross section multi-wired -
0.75 Square millimetre
Connectable conductor cross section solid-core -
0.75 Square millimetre
Depth -
51 Millimetre
Height -
51 Millimetre
Inflammability class of insulation material acc. with UL94 -
V2
Mounting method -
DIN rail (top hat rail) 35 mm
Number of potentials -
2
Operating temperature -
-60 Degrees celsius
Rated current In -
125 Ampere
Rated voltage -
800 Volt
Type of electrical connection 1 -
Screw connection
Type of electrical connection 2 -
Screw connection
Width -
15.2 Millimetre

Availability On Request

£12.26
